7
2 Setup for Installation
No. 99MBE011A

Direction
Symbol Direction
1
Forward: PA phase
advance
2
Reverse: PB phase
advance

Detector cable
Symbol
Length
(m)
Coil spring Connector
A 0.3 Available
Self-water-
proof
B 0.3
Not available
C 1
D 3
Not available
Not avail-
able
E 4
F 5
H 7
J 8
K 9
Tips
Non-coil spring cables are vinyl coated.

Signal cable
Symbol
Length
(m)
Metalexible
A 3 Available
B 3 Not available
C 5 Available
D 5 Not available
E 7 Available
F 7 Not available
G 3 Not available
H 5 Not available
J 7 Not available
X No signal cable
Tips
• Non-metal exible cables are vinyl coated.
• A half-pitch connector is used on the feedback cable side for G, H, and J.
