© MOBATIME 15 / 120 800652.11
5 Installation
5.1 Installation Guidelines
Danger! Always consider:
For mains power supply, a plug is located on the rear side of the DTS 4801 / DTS
4802. This power plug separates the device from the power.
The DTS 480x must be unplugged from the mains power supply for maintenance
or wiring by pulling this plug.
The plug supplied may only be connected by a licensed electrician.
The effective national installation requirements and guidelines must be followed.
5.2 Connections
The connections are specified in Appendix "A Connection diagrams".
Only connect the designated devices to the various inputs and outputs.
5.3 Boot procedure of the DTS 480x.masterclock
The normal booting time of the DTS 480x is approx. 60 sec. with pre-set IP or with
DHCP. The booting procedure of the operating system is displayed on the serial
console. After that, the text "starting" appears on the display (during the booting
procedure the display is dark and empty). Without connection to a DHCP server, the
first start up can take up to 75 seconds. After that, the DHCP option must be set to "off"
in the network configuration.
The display “starting“ remains until the time of output to the lines.
The duration, depending on the configuration, is 5-30 sec.
5.4 Firmware
It is recommended to install the current firmware on your device prior to the definite
commissioning. The current firmware can be found under www.mobatime.com
Customer Data Product Ressources Time Server.
