© MOBATIME 75 / 120 800652.11
7.8 SCP Connection
SCP = Secure Copy Protocol
Important:
SCP connection can only be established when no menu (operation) is
open.
The following error message can be ignored. There is no influence in the functionality
of the operation:
Command 'groups'
failed with termination code 127 and error message
-sh: groups: not found.
SCP-Tools
Windows 98, ME, 2000, XP, Vista,
Windows 7
Linux (Suse, Redhat)
Integrated in the system
(file manager):
- With command line
Programs (examples) WinSCP -
7.9 Save configuration externally
(for backup or copy to another DTS 480x)
Save the current configuration via MOBA-NMS:
1. Select DTS device in the device view.
2. Menu ‘Edit‘ Select ‘Backup configuration…‘.
3. Select the elements that are to be saved. (In case of doubt, select everything)
4. Click button ‘Next >‘.
5. Indicate destination file by clicking the ‘Browse…‘ button.
6. Optionally: enter a free backup comment. E.g. reason for the backup, use, etc.
This comment will then be shown during the restoration of the backup.
7. By clicking the ‘Finish‘ button, the backup is created.
8. At the end of the backup, an overview of the process is shown. It shows which
elements were saved and which ones are not available or could not be saved.
Save the current configuration via FTP:
1. Connect a FTP client software to the DTS 480x (with Internet Explorer enter:
ftp://dts@[IP address]) (as user dts).
2. Change to the DTS 480x directory /etc.
3. Save the file dts4801.conf (configuration) to the user PC (e.g. copy the file to the
Desktop or to the directory My Documents).
4. Additionally also save possible telegram and program files from the DTS 480x
directory /var/local/dts.
