© MOBATIME 83 / 120 800652.11
9 SNMP
9.1 General
The SNMP version V2c or V3 for Get, Put and Notification (Trap) is used.
A full SNMP agent is implemented on the DTS 480x.masterclock (MIB II, DTS480x).
For SNMP V2c, following standard Communities are used:
Read only: romobatime
Read/write: rwmobatime
Trap: trapmobatime
For SNMP V3, following standard User I Passwords are used:
dtsUser1: mobatime
dtsUser2: mobatime
dtsInfo: mobatime (not changeable, read only)
DtsUser1 and dtsUser2 have full read/write access on all objects. With SNMP V3 rules,
access can be reduced. But the access can be restricted with corresponding SNMP V3
rules.
SNMP V3 agent supports user validation (authentication MD5) and encoding
(encryption DES).
The following MIB definitions are used:
SNMPv2-SMI, SNMPv2-MIB, SNMPv2-CONF, SNMPv2-TC, SNMPv2-TM,
SNMP-FRAMEWORK-MIB, SNMP-MPD-MIB, SNMP-NOTIFICATION-MIB,
SNMP-TARGET-MIB, SNMP-USER-BASED-SM-MIB, SNMP-VIEW-BASED-ACM-MIB,
RFC1213-MIB, IF-MIB, IP-MIB, IP-FORWARD-MIB, TCP-MIB, UDP-MIB,
HOST-RESOURCES-MIB, HOST-RESOURCES-TYPES, DISMAN-EVENT-MIB,
NOTIFICATION-LOG-MIB, UCD-SNMP-MIB, NET-SNMP-MIB, NET-SNMP-TC
SNMP V2c,V3:
DTS-COMMON (File: DTS-COMMON-MIB.TXT)
General DTS definition, always required
DTS480x (DTS480x-MIB.TXT)
Device specific DTS definitions
SNMP V1:
DTS-COMMON (File: DTS-COMMON-MIBv1.TXT)
General DTS definition, always required
DTS480x (DTS480x-MIBv1.TXT)
Device specific DTS definitions
The MIB files can be copied from the DTS 480x.masterclock with FTP (for FTP use,
see chapter “7.6 FTP Connection“):
DTS-MIB: /etc/snmp/mibs/
Standard MIBS: /usr/share/snmp/mibs/
