B CLASSIC / B FUTURA / S CLASSIC - TECHNICAL MANUAL
ALARMS
2.3 HAZARD ALARMS - CODE “H”
List of alarm codes, messages displayed on the LCD and relative RESET modes:
CODE ALARM DESCRIPTION INDICATION ON LCD MODE
HAZARD (category H)
H 150 The MPX pressure sensor is broken MPX INTERRUPTED 2
H 160 MPX pressure sensor short-circuited/not connected MPX SHORT-CIRCUITED 2
H 400 Pconv/T ratio not balanced (Pconv>T) (PROCESS phase) INCORRECT P/T RATIO 2
H 401 T/Pconv ratio not balanced (T>Pconv) (PROCESS phase) INCORRECT P/T RATIO 2
H 402
Temperature above the MAXIMUM limit
(PROCESS phase)
T ABOVE MAX LIMIT 2
H 403
Temperature below the MINIMUM limit
(PROCESS phase)
T BELOW MIN LIMIT 2
H 404
Temperature uctuating over limit
(process phase)
T FLUCTUATING OVER
LIMIT
2
H 405
Pressure above MAX limit
(PROCESS phase)
P ABOVE MAX LIMIT 2
H 406
Pressure below MIN limit
(PROCESS phase)
P BELOW MIN LIMIT 2
H 410
Retention time incorrect
(PROCESS phase)
TIMER PROBLEM 2
H 990
Excessive pressure
(sterilization chamber - MPX)
EXCESSIVE PRESSURE 2
H 991
Overheating
(sterilization chamber - PT1)
PT1 OVERHEATING 2
H 992
Overheating
(steam generator - PT2)
PT2 OVERHEATING 2
H 993
Overheating
(tube bundle heating element - PT3)
PT3 OVERHEATING 2
1 = OK (warning) - Tap OK on pop-up window.
2 = OK + door unlock / RESET - Keep OK pressed for 3 seconds on the pop-up window and the autoclave will start
the procedure to open the door in full safety. When the RESET key appears in the left area of the LCD, hold it pressed
for 3 seconds.
2.4 ACCESSORY ALARMS - CODE “S”
List of alarm codes, messages displayed on the LCD and relative RESET modes:
CODE ALARM DESCRIPTION INDICATION ON LCD MODE
ACCESSORIES (category S)
S 001 Flash memory not accessible
FLASH MEMORY NOT
ACCESSIBLE
2
S 002 Flash memory full FLASH MEMORY FULL 2
S 003 SD memory card not accessible SD CARD NOT ACCESSIBLE 2
S 004 SD card full SD CARD FULL 2
S 005 USB stick not accessible USB STICK NOT ACCESSIBLE 2
S 006 USB stick not accessible USB STICK NOT ACCESSIBLE 2
S 007 USB stick full USB STICK FULL 2
S 008
SD Card not accessible
(touch only-impossible to transfer data)
SD CARD NOT ACCESSIBLE 2
S 009 Printer not connected NO PRINTER 2
S 010 Paper out or printer set-up error PRINTER: PAPER OUT 2
