B CLASSIC / B FUTURA / S CLASSIC - TECHNICAL MANUAL
ALARMS
LCD H 992 Indication Alarm description Effect / Symptom
PT2 OVERHEATING
PT2 overheating (steam
generator).
Temperature inside chamber exceeds 230°C.
Possible causes / Checks Solution
Steam generator
temperature sensor PT2 is
damaged.
Change sensor PT2 - see ST1-Steam generator datasheet.
The electronic card is
damaged.
Change the electronic card.
LCD H 993 Indication Alarm description Effect / Symptom
PT3 OVERHEATING
PT3 overheating (tube bundle
heating element).
Temperature inside chamber exceeds 200°C.
Possible causes / Checks Solution
Tube bundle heating
element temperature
sensor PT3 is damaged.
Change sensor.
The electronic card is
damaged.
Change the electronic card.
2.8 LCD S INDICATIONS
S 001
LCD Indication Alarm description Effect / Symptom
FLASH MEMORY NOT ACCESSIBLE Flash memory not accessible. Failure to access ash memory.
Possible causes / Checks Solution
Flash memory is damaged. Change the electronic card.
The electronic card is damaged. Change the electronic card.
S 002
LCD Indication Alarm description Effect / Symptom
FLASH MEMORY FULL Flash memory full. Flash memory full.
Possible causes / Checks Solution
Flash memory is damaged. Change the electronic card.
Flash memory is full. Change the electronic card.
The electronic card is damaged. Change the electronic card.
S 003
LCD Indication Alarm description Effect / Symptom
SD CARD NOT ACCESSIBLE SD Card not accessible (missing). Failed SD Card reading.
Possible causes / Checks Solution
Incorrect SD Card positioning/locking.
Check SD Card proper installation.
Check SD Card proper locking.
Change the electronic card.
SD Card is damaged. Change the electronic card.
The electronic card is damaged. Change the electronic card.
S 004
LCD Indication Alarm description Effect / Symptom
SD CARD FULL SD card full.
Possible causes / Checks Solution
SD memory card is damaged. Change the electronic card.
SD memory card full. Free SD Card memory space using SERVICE menu/COUNTER RESET-SQ24.
The electronic card is damaged. Change electronic card – see relevant datasheet.
