B CLASSIC / B FUTURA / S CLASSIC - TECHNICAL MANUAL
ALARMS
LCD A 102 Indication Alarm description Effect / Symptom
PT2 INTERRUPTED
Steam generator temperature
sensor PT2 interrupted.
Control system detects interruption in PT2 and its
wiring.
Possible causes / Checks Solution
Problem with PT2 wiring –
check wiring.
Check condition of PT2 to electronic card wiring connection.
Problem with PT2
interruption – check sensor.
Look at cycle report to determine alarm intervention point.
Disconnect PT2 sensor from electronic card.
Check for continuity and measure resistance, which should be between 1000 and
1500 ohm.
Change PT2 - see technical datasheet ST01 - STEAM GENERATOR.
Problem with electronic
card.
Change electronic card.
LCD A 103 Indication Alarm description Effect / Symptom
PT3 INTERRUPTED
Temperature sensor PT3 of
chamber tube bundle heating
element interrupted.
Control system detects interruption in PT3 and its
wiring.
Possible causes / Checks Solution
Problem with PT3 wiring –
check wiring.
Check condition of PT3 to electronic card wiring connection.
Problem with PT3
interruption – check sensor.
Look at cycle report to determine alarm intervention point.
Disconnect PT3 sensor from electronic card.
Check for continuity and measure resistance, which should be between 1000 and
1500 ohm.
Change PT3.
Problem with electronic
card.
Change electronic card.
LCD A 105 Indication Alarm description Effect / Symptom
PT5 INTERRUPTED
Temperature sensor PT5 for
conductivity sensor measurement
compensation interrupted.
Control system detects interruption in PT5 and its
wiring.
Possible causes / Checks Solution
Problem with PT5 wiring –
check wiring.
Check condition of wiring connecting conductivity sensor to electronic card.
Problem with PT5
interruption – check sensor.
Disconnect conductivity sensor from electronic card.
Check for continuity.
Change conductivity sensor.
Problem with electronic
card.
Change electronic card.
LCD A 111 Indication Alarm description Effect / Symptom
PT1 SHORT-CIRCUITED
Sterilization chamber temperature
sensor PT1 short-circuited.
Control system detects a short circuit in PT1 and its
wiring.
Possible causes / Checks Solution
Problem with PT1 wiring –
check wiring.
Check condition of PT1 wiring paying special attention to electronic card connector.
Problem with PT1 sensor –
check sensor.
Check PT1 resistance.
Change sensor PT1 - see technical datasheet ST05 - PT1 SENSOR - CHAMBER
TEMPERATURE SENSOR..
