ModWeigh MW93A - MD2 Display; MP2 Processor; MD1 Display; MP1 Processor

EMC INDUSTRIAL GROUP LTD Connections
MW93A_IM_ALL_SV6.09f_en 11/59
MD2 Display
MP2 Processor
MD1 Display
MP1 Processor
MT1 Transmitter
MT3 Transmitter
MR1 Remote IO
Connections
Motor integration
The following diagrams show various methods to connect a ModWeigh to a VSD drive or motor contac-
tor.
VSD Drive, keypad run/stop
ModWeigh keypad used to start and stop the system. Can be used for batching applications.
VSD Drive, VSD run/stop
ModWeigh slaved from VSD running signal.
+
−
AO1
+
−
VSD speed input
4-20mA
VSD run input
run motor [OUT3, 56]
+24V 0V
NOT stop [INx, -1]
VSD OK
136mm
66mm
20mm
8mm
optional DIN rail mount
approx. 35
0g
156mm
86mm
136mm
66mm
20mm
50mm
8mm
optional DIN rail mount
approx. 35
0g
136mm
66mm
20mm
50mm
8mm
optional DIN rail mount
approx. 35
0g
PANEL cut out
186 x 92 mm
-0.0 + 1.0 mm
FACIA
208 x 104 mm
top view
approx. 450g
104mm
30mm
8mm
208mm
PANEL cut out
138 x 67 mm
-0.0 + 1.0 mm
FACIA
144 x 72 mm
top view
approx. 400g
72mm
80mm
9mm
144mm
