EMC INDUSTRIAL GROUP LTD Basic Settings
MW93A_IM_ALL_SV6.09f_en 50/59
5. Press the 1 key followed by ENTER to start the tuning.
6. Press and hold the BACK key to return to normal operation.
7. The tuning progress is displayed on a bar graph.
8. If the tuning was unsuccessful, an alarm is raised at completion.
SETUP – DISPLAY
Basic Settings
Clock
The display has a clock whose data is sent to each transmitter connected to it. The clock is used to date
stamp printouts and can cause printouts (or other events) to occur at user set times during the day or
week. The clock will run continue to run for a few days or weeks without power. The time is also shown
in the top right corner of the display (if no alarms are present).
Q92191 clock enable 9910 0
Set to 0 to disable the clock or 1 to enable the clock. When disabled, time & date information is not
shown on any printouts.
Daylight saving
Q921921 locality 9912 0
Selects the locality for daylight saving correction. Use the UP & DOWN keys to select a locality or set to
0 to disable daylight saving correction or set to CUSTOM to set your own correction dates. If CUSTOM is
selected, the following three settings specify when the correction will be made.
Q921922 weekday & time for DST 9914
20
Selects the day of the week and time when the daylight saving correction will be made.
Q921923 start of daylight saving 9916 0
Selects the time of the year when daylight saving will start.
Q921924 end of daylight saving 9918 0
Selects the time of the year when daylight saving will end.
Q921925 daylight saving time (DST) 9920 0
Shows if daylight saving is on or off. If automatic daylight saving correction is off, then this setting may
be used to move the clock forwards or backwards by one hour.
Set clock
Q921931 set date 9922
Sets the date. For example to set 9 March 2007, enter 070309.
Q921932 set time 9924
Sets the time in 24hour format.
Communications & Display
Comms port 1 – RS232
Q92511 COM1 baud rate (8 data, no parity, 2 stop) 8580 19200
Q92512 COM1&2 modbus address [1 to 30] 8592 30
Q92513 COM1 stop bits 18052 0
Q92514 COM1 mode 18060, g12 0
COM1 mode description
0 auto : use extended modbus
1 modbus : use standard modbus
Q92515 COM1 handshake enable [0=disable, 1=enable] 8584 0
Q92510 COM1 error count 8810
Comms port 2 – RS485
Q92521 COM2 baud rate (8 data, no parity, 2 stop) 8590 230400
Q92522 COM1&2 modbus address [1 to 30] 8592 30
Q92523 COM2 stop bits 18054 0
20
Defaults to whatever the current setting is.
