ModWeigh MW93A - Usb

EMC INDUSTRIAL GROUP LTD Communications & Display
MW93A_IM_ALL_SV6.09f_en 48/59
Q25661 key A function & lock 8690, g4 0
Q25662 key B function & lock 8692, g4 3
Q25663 key C function & lock 8694, g4 5
Q25664 key D function & lock 8696, g4 2
Q25665 key E function & lock 8698, g4 1
Signal customisation
These settings allow the names and units of any signal to be changed.
Signal 1
Q256711 signal 1 source 18000
Q256712 signal 1 name 4000
Q256713 signal 1 type 18010
Signal 2
Q256721 signal 2 source 18002
Q256722 signal 2 name 4100
Q256723 signal 2 type 18012
Signal 3
Q256731 signal 3 source 18004
Q256732 signal 3 name 4200
Q256733 signal 3 type 18014
Signal 4
Q256741 signal 4 source 18006
Q256742 signal 4 name 4300
Q256743 signal 4 type 18016
Signal 5
Q256751 signal 5 source 18008
Q256752 signal 5 name 4400
Q256753 signal 5 type 18018
USB
The controller setup can be saved to a file on a USB drive. The setup may also be loaded from a saved
file. User log files and system log files can also be saved to the drive.
Q2581 save setup 8938
Set to 1 to save the setup to a file on a USB drive. It is saved in a folder called ModWeigh\Setup. The
file will be named ‘AA PP SSSSS MM.csv, where AA is the modbuss address of the unit, PP is the prod-
uct number, SSSSS is the units serial number and MM is the model of the unit.
The file is a comma separated list of settings, strings and memory storage which can be viewed as a
spreadsheet.
Q2582 select ‘load setup’ file 8940
This allows a file to be selected to be loaded. The file must have a .csv extension and must be in a
folder called Setup which itself must be in a folder called ModWeigh. To select a file, press the ‘C’ key
to show a list of the files found.
Q2583 load setup 8942
Use the UP and DOWN keys to select what data to load from the selected file.
setting lock function
1 exclude: strings, memory storage, loadcell calibration,
totaliser, comms, calibration lock
2 load strings (macros)
3 load memory storage
4 load loadcell calibration
Q2584 save user log 8944
Q2585 save system logs 8946
Display settings
The following settings only appear in MP1,MP2.
Q25693 disable beeper 8518 0
Q25694 comms latency 8510 0 mS
