EMC INDUSTRIAL GROUP LTD Internal Signals
MW93A_IM_ALL_SV6.09f_en 40/59
Q23744 weight feed forward % 8496, g9 0.0 %
Sets the percentage increase in speed demand if the hopper emptied completely.
Q23745 weight feed forward limit 8498, g9 50 kg,t,g
This is the weight below which the weight feed forward begins to be applied.
Q23746 tune feed forward time 8490, g9 0.0 min
Automatic adjustment is disabled if the ‘tune feed forward time’ is set to zero. Sets a rate at which the
feed forward values are automatically adjusted.
Memory Storage
Memory storage is used to save or recall a group of settings to memory. This can for example be used
to save different settings that change for different products. The instrument can store up to 20 groups
of settings.
Memory Setup
Q23811 memory usage 8680, g8 0
Selects how the memory will be used. Several preset choices are available or it may be set for a custom
setup.
memory usage
description default memory store name
0 disabled
1 custom
2 setpoint 1 PRODUCT
3 setpoints 1 & 2 PRODUCT
4 loadcell calibration CALIBRATION
5 flowrate setpoint PRODUCT
6 feed forward PRODUCT
Q23812 data 1 source 8670, g8 0
Q23813 data 2 source 8672, g8 0
Q23814 data 3 source 8674, g8 0
Q23815 data 4 source 8676, g8 0
The four items above contain the addresses of settings that will be stored in the group memory. The
addresses can only be set if the memory usage is set to ‘custom’.
Q23810 memory store name 3600, g8
This sets a name for the memory store. If a text name is entered, it will replace the word ‘GROUP’ in
the following memory settings.
% Increase In Speed Demand
weight feed forward limit
flowrate at 100% speed
Speed Demand
