EMC INDUSTRIAL GROUP LTD Communications & Display
MW93A_IM_ALL_SV6.09f_en 44/59
Registers 2
Q25421 no function 8020, g12
Q25422 no function 8022, g12
Q25423 no function 8024, g12
Q25424 no function 8026, g12
Q25425 speedC 8028, g12
Q25426 ratioC 8030, g12
Q25427 setpointC 8032, g12
Q25428 control2 & control3 8034, g12
Q25429 control1C & control1G 8036, g12
Q25420 IO Control 8038, g12
Printing & Macros
Q2551 print settings and macros
16
8922, g13 0
Used to start a print out of the settings or of the macros. Select the number of the print out required.
number printout
1 print quick settings
2 print main settings
3 print service macros
4 print altered settings
5 print altered macros
6 print all macros
Print options
Q25521 print continuous rate
17
8610, g13 0
Sets the rate at the which the print continuous macro is run. Use the UP and DOWN keys to select the
rate.
Q25522 disable macros [0=off, 1=on] 8616, g13 0
Disables all macros from running. This includes the system name macro.
Q25523 event print control 8586, g13 0
Controls what data is logged to the internal User Log File
control description
1 None
2 AlarmLog
3
4 BatchSummary
5
6 BatchDetail
Q25524 key macro options 8508, g13 0
Sets the behaviour of some of the operator key functions such as START and STOP.
options description
0 - 9 Preset options (fixed).
10-19
Behavour maybe customised with the Key Macros. The default macros are the
same as the preset options. e.g. If set to 10, the default Key Macro is the same
as when the option is set to 0. Similarly 11 to 1, 12 to 2 etc.
Q25525 macro output select 8506, g13 0
Selects which port data from macros and ‘event print control’ is output. By default, data is output on
the controllers COM1 (RS232) port.
Ports on other devices connected to the controller can be selected, including some RS485 ports and
USB virtual comm ports.
Macros
Q25531 print macro 1000, g13
This macro is run when PRINT is activated.
16
0=press EDIT then use up & down keys to select printout, 1=print quick settings, 2=print main settings, 3=print service settings,
4=print altered settings, 5=print altered macros, 6=print all macros
17
0=off, 1=100Hz, 2=50Hz, 3=20Hz, 4=10Hz, 5=5Hz, 6=2Hz, 7=1Hz, 8=2s, 9=5s, 10=10s, 11=30s, 12=1min, 13=2min, 14=5min,
15=10min
