Info, Resets & Final Cal
Basic Settings
Inputs Internal Signals Outputs
Communications & Display
Information, Resets & Final Calibration
Product Information
These settings can only be viewed, and show important features of the transmitter.
Q2611 system name 8844
19
Weight Change 1
Displays the name of the product. This is usually displayed on the top line of a ModWeigh display. It is
created by the system name macro.
Q2612 product serial number 8852
Displays the serial number of the product
Q2613 software version number 8854
Displays the version number of the software currently installed in the product.
Q2614 CPU type 8858
Displays the CPU type.
Q2615 product key 8864
Displays the product key if it has been applied.
Q2616 P-Module serial number 8860
Displays the serial number of the P-Module.
Q2617 MR1 serial number 8862
Displays the serial number of the MR1 unit if connected.
Q2618 MO3 serial number 8866
Displays the serial number of the MO3 option if fitted.
Reset settings
Q2631 reset loadcell calibration (1=reset to defaults) 8950 0
Set to 1 to reset the loadcell calibration to the default.
Q2632 reset comms settings (1=reset to defaults) 8952, g12 0
Set to 1 to reset the comms settings back top their defaults.
Q2633 reset other settings (1=reset to defaults) 8954 0
Set to 1 to reset all user settings to the defaults. A Quick or Main setup is required next. Does not
reset the loadcell calibration, comms settings or any of the macros.
Reset macros
Q2641 reset all macros (1=reset to defaults) 8956, g13 0
Set to 1 to reset all the macros to the defaults. Does not reset any settings.
Final calibration
* Q2653
auto-tune control settings [0=stop, 1=start]
8900, g00
Set to 1 to start the auto-tune process, or to 0 to stop the process.
Run an Auto-Tune Process
An auto-tune process will measure the flowrate at speeds of 80% and 20% for a period of time while
the flowrate is monitored. If successful, the following control settings are adjusted;
• proportional band
• integral time constant
• speed at zero flowrate
• flowrate at 100% speed
• flowrate disturbance hold
• system time constant
• transport delay
1. Make sure the system is running with material.
2. Press the Q key to access the setup menu.
3. Key in the quick key code 2653 to select the ‘auto-tune control settings’ step.
4. Press the EDIT key. (If editing is locked, key in the password 111 and press ENTER).
19
Defined by the “system name macro” at Quick Key 25541
