EMC INDUSTRIAL GROUP LTD Macros
MW94A_IM_ALL_SV6.09f_en 22/53
Alternate Instructions
188
ALT0 ‹arg1› ‹arg0›
UC = (arg0 - 1) + (arg1 - 1) × 128
189
ALT1 ‹arg1› ‹arg0›
UC = (arg0 - 1) + (arg1 - 1) × 128 + 16384
190
ALT2 ‹arg1› ‹arg0›
UC = (arg0 - 1) + (arg1 - 1) × 128 + 32768
191
ALT3 ‹arg1› ‹arg0›
UC = (arg0 - 1) + (arg1 - 1) × 128 + 49152
Register Instructions
192 NOP no operation
193 RECALL “register” “register” is an ASCII Modbus address (8000 to 8992).
194
RECALL ‹argument›
‹argument› register
1 weight
2 gross weight
3 net weight
4 zero weight
5 tare weight
6 total weight
7 running total
8 peak weight
9 flow rate
10 belt speed
11 current setpoint
12 speed demand
13 COM 2 modbus address
14 print settings & macros
15 product serial number
16 flowrate raw
17 temp 1
18 temp 2
19 perm 1
20 perm 2
21 P_Module serial number
22 perm3
23 perm4
24 perm5
25 temp3
26 temp4
27 temp5
28 batch setpoint
29 batched weight
30 batch number
31 last batched weight
32 number to batch
101 with address in VALUE
102 default_value
103 minimum_value
104 maximum_value
105 column
106 memory
107 register_number
108 port
109 slave_address
Other aruments are invalid and not all arguments
available in all products.
195 STORE “register” “register” is an ASCII Modbus register (8000 to 8992).
196 STORE ‹argument› ‹argument› selects register. See RECALL instruction.
197 MENU ‹argument›
‹argument› action
1 start_menu
3 next_quick
5 next_service
6 next_factory
7 next_altered
198 MACRO ‹argument›
‹argument› action
1 start_macro
2 next_macro
3 next_ altered _macro
Print Instructions
200 PRINT_VALUE
201 PRINT_NAME
202 PRINT_UNITS
203 PRINT_HINT
204 PRINT_DATE
205 PRINT_TIME
206 PRINT_SECONDS
“format” is an ASCII format code of the form CcDdBb. c is the column
width, d is the number of decimal places and b is the count by. Any one
or combination of the three parts can be included. (e.g. C10d2b5 sets the
column width to 10, the decimal places to
2 and the count by to 5; C10
sets column width to 10). The default is 0.
