EMC INDUSTRIAL GROUP LTD Basic Settings
MW94A_IM_ALL_SV6.09f_en 28/53
SETUP – MW94A IMPACT WEIGHER
Basic Settings
Basic Settings
Inputs Internal Signals Outputs
Communications & Display
Information, Resets & Final Calibration
Engineering units
These settings affect the engineering units that will be used for many other settings. The engineer-
ing units can be changed at any time. Note that you must enter settings in the same units as set
here eg 750 g calibration weights must be entered as 0.75 kg if the weight units are kg.
Q2111 units metric/imperial [0=both, 1=metric, 2=imperial] 8042, g0
Selects between metric units, imperial units or any if a mixture of metric and imperial units is required.
Q2112 weight units 8044
1
kg=101
These are the engineering units that will be used for all weight settings except the totaliser (eg kg).
Q2114 flowrate units 8048, g0
2
t/h=164
These are the engineering units that will be used for all flowrate settings (eg t/h).
Q2115 totaliser units (TU) 8050, g0
3
t=102
These are the engineering units that will be used for the totaliser (eg t).
Measuring range
If a signal exceeds the capacity setting, it will display as over-range. Therefore the range settings
should be set larger than the maximum value that will occur during normal operation.
The measuring range affects the way many other settings are stored and displayed. These other set-
tings are stored internally as a percentage of the relevant capacity. Once these capacities are set, the
other settings, eg the analog output, will automatically work. Note that, in particular, the ‘weight capac-
ity’ must be set before any other weight settings are entered.
4
* Q2121 weight capacity (WCAP) 8060 100.0 kg,t,g
* Q2123 flowrate capacity (FCAP) 8064 600 t/h,kg/h
Display resolution
The division settings affect to what resolution a signal is displayed. For most practical weighing sys-
tems, the total number of divisions will be within the range 500 to 5000.
Q2131 weight division 8070, g0 0.2 kg,t,g
Q2133 flowrate division 8074, g0 1 t/h,kg/h
Trade setup
Q2141 trade use check 8702, g7
Displays off if instrument is not suitable for trade use. Information on what needs changing for trade
use is shown.
Q2142 calibration verification code 8714, g7
Whenever a setting is changed which may alter the trade calibration of the instrument, this value will
change. It can be used to check if the calibration has been changed since this value was last recorded.
Q2143 calibration lock 8078, g7 off=0
When set to on, all settings which effect the trade calibration are locked.
Clock
The unit has a real time clock. The clock is used to date stamp printouts and can cause printouts (or
other events) to occur at user set times during the day or week. The clock will run continue to run for a
few days or weeks without power. The time is also shown in the top right corner of the display (if no
alarms are present).
Q2191 clock enable 9910 0
Set to 0 to disable the clock or 1 to enable the clock. When disabled, time & date information is not
shown on any printouts.
1
Metric: 100=g, 101=kg, 102=t, Imperial: 110=oz, 111=lb, 112=tons
2
Metric: 160=kg/s, 161=kg/min, 162=kg/h, 163=t/min, 164=t/h, Imperial: 170=lb/s, 171=lb/min, 172=lb/h, 173=ton/min,
174=ton/h
3
Metric: 100=g, 101=kg, 102=t, Imperial: 110=oz, 111=lb, 112=tons
4
* Appears in Quick Setup menu. These are the most important setting for this controller.
