ModWeigh MW94A - User Data

EMC INDUSTRIAL GROUP LTD Internal Signals
MW94A_IM_ALL_SV6.09f_en 35/53
memory usage description default memory store name
0 disabled
1 custom
2 setpoint 1 PRODUCT
3 setpoints 1 & 2 PRODUCT
4 loadcell calibration CALIBRATION
5 calibration constant K
6 not used
Q23812 data 1 source 8670, g8 0
Q23813 data 2 source 8672, g8 0
Q23814 data 3 source 8674, g8 0
Q23815 data 4 source 8676, g8 0
The four items above contain the addresses of settings that will be stored in the group memory. The
addresses can only be set if the memory usage is set to ‘custom’.
Q23810 memory store name 3600, g8
This sets a name for the memory store. If a text name is entered, it will replace the word ‘GROUP’ in
the following memory settings.
Memory Recall/Store
The following 3 settings are used to recall or store a group of settings and to set a name for each
group. The groups are numbered from 0 to 19. Unless the memory usage is disabled, these settings
will appear in the operator’s MENU, accessed by pressing the MENU key.
Q23821 recall GROUP 8816, g8 0
Q23822 store GROUP 8814, g8 0
Q23823 edit GROUP name 3700, g8
Edit Stored Memory
The following allow a group of stored settings to be altered without recalling them first. The ‘GROUP
to edit’ is set to the group number 0 to 19, and the remaining steps used to edit the stored values.
Q23831 GROUP to edit 8818, g8 0
Q23832 GROUP name 3800, g8
Q23833 data 1 source not used 8820, g8 0
Q23834 data 2 source not used 8822, g8 0
Q23835 data 3 source not used 8824, g8 0
Q23836 data 4 source not used 8826, g8 0
User data
Additional user data which for example may be used by macros.
The PERM settings are retained when the power is removed from the controller.
The TEMP settings are not retained when the power is removed from the controller.
Retained
Q23911 perm 1 8596, g13 0
Q23912 perm 2 8598, g13 0
Q23913 perm 3 8570, g13 0
Q23914 perm 4 8572, g13 0
Q23915 perm 5 8574, g13 0
Other data
Q23921 temp 1 8612, g13 0
Q23922 temp 2 8614, g13 0
Q23923 temp 3 8576, g13 0
Q23924 temp 4 8578, g13 0
Q23925 temp 5 8582, g13 0
Q23928 date 8830, g13
Displays the date in the form ‘YYMMDD’.
Q23929 time 8832, g13
Displays the time in the form ‘HHMM’.
