EMC INDUSTRIAL GROUP LTD Internal Signals
MW94A_IM_ALL_SV6.09f_en 34/53
Q23513 limit 1 delay 8352, g7 0.00 s
Sets a delay to activate or de-active the limit.
Q23514 setpoint 1 8330, g7
Sets the limit value.
Q23515 setpoint 1 preact 8356
Sets the preact value.
Limit 2
Q23521 limit 2 source (modbus address of signal) 8360, g7
Q23522 limit 2 mode 8364, g7 low limit = 1
Q23523 limit 2 delay 8362, g7 0.00 s
Q23524 setpoint 2 8332, g7
Q23525 setpoint 2 preact 8366
Limit 3
Q23531 limit 3 source (modbus address of signal) 8340, g7
Q23532 limit 3 mode 8344, g7 fill control = 4
Q23533 limit 3 delay 8342, g7 0.00 s
Q23534 setpoint 3H 8334
Q23535 setpoint 3L 8346
Events/Alarms/Faults
Various events can be triggered by the inputs (eg to capture the weight) or automatically when certain
situations are detected by the transmitter. Each event has an ID and produces a value.
Q2361 event ID 8780, g8
ID of most recent event.
Q2362 event value 8782, g8
Value of most recent event.
Q2363 last alarm event 8784, g8
Value of most recent event.
Q2364 alarm list (press EDIT to view list of all possible alarms) 8920, g8
Scroll through a list of all possible alarms.
Q2365 delay time [0.00 to 300.00] 8458, g8 0.00 s
A timer used by the macros.
Q2366 healthy options 8456, g8 0
Selects which faults control the healthy signal.
Q2369 fault options 8454
Allows selected faults to not raise an alarm.
Speed demand
The speed demand is a 0 to 100% signal used to control the flowrate.
Q23731 speed demand (flow control speed signal) 8792 %
Displays the control signal for the flowrate control.
Q23732 set manual speed 8482 %
Sets a manaul speed demand and sets volumentric mode.
Memory Storage
Memory storage is used to save or recall a group of settings to memory. This can for example be used
to save different settings that change for different products. The instrument can store up to 20 groups
of settings.
Memory Setup
Q23811 memory usage 8680, g8 0
Selects how the memory will be used. Several preset choices are available or it may be set for a custom
setup.
