ModWeigh MW94A - Comms Port 3 - RS485 MR1; Interface Registers; Printing & Macros

EMC INDUSTRIAL GROUP LTD Communications & Display
MW94A_IM_ALL_SV6.09f_en 38/53
Q2524 COM2 mode 8838, g12 0
COM2 mode description
0 auto : use mwbus – automatic fall back to modbus slave
1 modbus : use standard modbus
If this port is connected to an external modbus master, then this should be set to modbus.
Q2520 COM2 error count 8812, g12 Hz
Shows the operating mode (MWBUS or MODBUS). The ‘cycle time’ is the MR1 update rate. A list of
device addresses on the bus is shown.
Communications error counts are shown, which should usually
read 0.
Comms port 3 - RS485 MR1
Q2531 COM3 baud rate (8 data, no parity, 2 stop) 8588, g12 115200
Sets the communications speed.
Q2533 COM3 stop bits 18056, g12 0
Interface registers
These registers are the recommended registers to use for extracting the basic signals from the trans-
mitter via Modbus. The advantage of using these registers is that multi-register Modbus commands can
be used to make the interface more efficient.
A control or status register contains 32 bits of on or off information. When one of these registers is
displayed, a bit is selected by using the left and right arrow keys.
Registers 1
Q25411 gross weight 8000, g12
Q25412 no function 8002, g12
Q25413 speed demand 8004, g12
Q25414 no function 8006, g12
Q25415 total weight 8008, g12
Q25416 flowrate 8010, g12
Q25417 control1 & control2 8012, g12
Q25418 control3 & status1 8014, g12
Q25419 status2 & status3 8016, g12
Q25410 IOx & faults 8018, g12
Registers 2
Q25421 no function 8020, g12
Q25422 no function 8022, g12
Q25423 no function 8024, g12
Q25424 no function 8026, g12
Q25425 speedC 8028, g12
Q25426 ratioC 8030, g12
Q25427 setpointC 8032, g12
Q25428 control2 & control3 8034, g12
Q25429 control1C & control1G 8036, g12
Q25420 IO Control 8038, g12
Printing & Macros
Q2551 print settings and macros
15
8922, g13 0
Used to start a print out of the settings or of the macros. Select the number of the print out required.
number printout
1 print quick settings
2 print main settings
3 print service macros
4 print altered settings
5 print altered macros
6 print all macros
15
0=press EDIT then use up & down keys to select printout, 1=print quick settings, 2=print main settings, 3=print service settings,
4=print altered settings, 5=print altered macros, 6=print all macros
