EMC INDUSTRIAL GROUP LTD Communications & Display
MW94A_IM_ALL_SV6.09f_en 39/53
Print options
Q25521 print continuous rate
16
8610, g13 0
Sets the rate at the which the print continuous macro is run. Use the UP and DOWN keys to select the
rate.
Q25522 disable macros [0=off, 1=on] 8616, g13 0
Disables all macros from running. This includes the system name macro.
Q25523 event print control 8586, g13 0
Controls what data is logged to the internal User Log File
control description
1 None
2 AlarmLog
3
4 BatchSummary
5
6 BatchDetail
Q25524 key macro options 8508, g13 0
Sets the behaviour of some of the operator key functions such as START and STOP.
options description
0 - 9 Preset options (fixed).
10-19
Behavour maybe customised with the Key Macros. The default macros are the
same as the preset options. e.g. If set to 10, the default Key Macro is the same
as when the option is set to 0. Similarly 11 to 1, 12 to 2 etc.
Q25525 macro output select 8506, g13 0
Selects which port data from macros and ‘event print control’ is output. By default, data is output on
the controllers COM1 (RS232) port.
Ports on other devices connected to the controller can be selected, including some RS485 ports and
USB virtual comm ports.
Macros
Q25531 print macro 1000, g13
This macro is run when PRINT is activated.
Q25532 print total macro 1100, g13
This macro is run when PRINT TOTAL is activated.
Q25533 print remote macro 1200, g13
This macro is run when a digital input with the function print, is activated.
Q25534 print total remote macro 1300, g13
This macro is run when a digital input with the function print total, is activated.
Q25535 user function 1 macro 3200, g13
Q25536 user function 2 macro 3300, g13
Q25537 user function 3 macro 3400, g13
These macros run when the user function (in the operator menu) is activated.
Macro subroutines
Q25541 system name macro 2000, g4
This macro sets the units name. This name is displayed by the display to identify the unit.
Q25542 print key subroutine 2100, g13
A subroutine used by the print key macro.
Q25543 print total key subroutine 2200, g13
A subroutine used by the print total key macro.
Q25544 settings subroutine 2300, g13
A subroutine used by the print settings macro.
Q25545 macros subroutine 2400, g13
A subroutine used by then print settings macro.
Q25546 heading subroutine 2500, g13
A subroutine used by the several macros to identify the unit on the printout.
16
0=off, 1=100Hz, 2=50Hz, 3=20Hz, 4=10Hz, 5=5Hz, 6=2Hz, 7=1Hz, 8=2s, 9=5s, 10=10s, 11=30s, 12=1min, 13=2min, 14=5min,
15=10min
