Signal 4
Q256741 signal 4 source 18006
Q256742 signal 4 name 4300
Q256743 signal 4 type 18016
Signal 5
Q256751 signal 5 source 18008
Q256752 signal 5 name 4400
Q256753 signal 5 type 18018
USB
The controller setup can be saved to a file on a USB drive. The setup may also be loaded from a saved
file. User log files and system log files can also be saved to the drive.
Q2581 save setup 8938
Set to 1 to save the setup to a file on a USB drive. It is saved in a folder called ModWeigh\Setup. The
file will be named ‘AA PP SSSSS MM.csv, where AA is the modbuss address of the unit, PP is the prod-
uct number, SSSSS is the units serial number and MM is the model of the unit.
The file is a comma separated list of settings, strings and memory storage which can be viewed as a
spreadsheet.
Q2582 select ‘load setup’ file 8940
This allows a file to be selected to be loaded. The file must have a .csv extension and must be in a
folder called Setup which itself must be in a folder called ModWeigh. To select a file, press the ‘C’ key
to show a list of the files found.
Q2583 load setup 8942
Use the UP and DOWN keys to select what data to load from the selected file.
setting lock function
1 exclude: strings, memory storage, loadcell calibration,
totaliser, comms, calibration lock
2 load strings (macros)
3 load memory storage
4 load loadcell calibration
Q2584 save user log 8944
Q2585 save system logs 8946
Display settings
The following settings only appear in MP1,MP2.
Q25693 disable beeper 8518 0
Q25694 comms latency 8510 0 mS
Info, Resets & Final Cal
Basic Settings
Inputs Internal Signals Outputs
Communications & Display
Information, Resets & Final Calibration
Product Information
These settings can only be viewed, and show important features of the transmitter.
Q2611 system name 8844
18
Impact Weigher 1
Displays the name of the product. This is usually displayed on the top line of a ModWeigh display. It is
created by the system name macro.
Q2612 product serial number 8852
Displays the serial number of the product
Q2613 software version number 8854
Displays the version number of the software currently installed in the product.
Q2614 CPU type 8858
Displays the CPU type.
Q2615 product key 8864
Displays the product key if it has been applied.
18
Defined by the “system name macro” at Quick Key 25541
