Value Display Description
0 N1U1 100t/h display flowrate
1 N1U1 hide flowrate
2048 N1U1 6543.21t display running total (in place of flowrate)
2049 (2048+1) N1U1 1000.00t display batch weight (in place of flowrate)
0 N2U2 1000rpm display speed (rpm)
2 N2U2 hide speed (rpm)
8192 N2U2 10.0t/h display flowrate (in place of speed [rpm])
8194 (8192+2) N2U2 1234.56t display total/batch weight (in place of speed [rpm])
8 hide zeroing status bar graph and icons
32 t/h hide flowrate units
64 t hide total/batch weight units
128 total weight include speed name
256 include limit icons
1024 do not display secondary line
Q25654 display select sourceA 8600, g14 0
Q25655 display select sourceB 8602, g14 0
The above two settings allow up to two additional settings to be added to the items displayed in the
bottom line of the display. These items are selected during normal use with the DISPLAY key.
Q25656 menu sourceA 8604, g14 0
Q25657 menu sourceB 8606, g14 0
Q25658 menu sourceC 8594, g14 0
The above three settings allow up to three additional settings to be added to the operator menu.
These items will appear in the menu shown when the MENU key is pressed during normal operation.
Q25659 display select options 8678, g14 0
Controls the select line at the bottom of the display.
Add up the numbers in the following table to change the display as described.
Value Description
1 permanently hide the whole line
2 hide the logo
Softkey customisation
These settings set the functions of each of the soft keys A, B, C, D and E.
Q25661 key A function & lock 8690, g4 0
Q25662 key B function & lock 8692, g4 3
Q25663 key C function & lock 8694, g4 9
Q25664 key D function & lock 8696, g4 4
Q25665 key E function & lock 8698, g4 8
Signal customisation
These settings allow the names and units of any signal to be changed.
Signal 1
Q256711 signal 1 source 18000
Q256712 signal 1 name 4000
Q256713 signal 1 type 18010
Signal 2
Q256721 signal 2 source 18002
Q256722 signal 2 name 4100
Q256723 signal 2 type 18012
Signal 3
Q256731 signal 3 source 18004
Q256732 signal 3 name 4200
Q256733 signal 3 type 18014
