05/06 AWB2724-1584GB
Tables of contents
3
to the controller 48
– canload 50
– setrtc 50
Using libraries 51
Installing other system libraries 51
EC4-200 specific functions 52
– EC_Util.lib library 52
– EC_Visu.lib library 52
Communication parameters of the PC 55
Communication parameters (baud rate) of the CPU 55
Overview 57
Structure of the INI file 57
Creating the Startup.INI file 57
Switching on the controller with the fitted memory
card containing the Startup.INI file 57
Changing parameters 58
Deleting the Startup.INI file 58
Requirements 59
Routing features of the controller 59
Routing through XC200 59
Notes on routing 60
Addressing 60
Procedure 61
PLC combinations for routing 62
Number of communication channels 62
Appendix 65
CAN/easy-NET network 65
– Accessories 65
Example program for PLC START/STOP using
external switch 66
Dimensions and weight 67
Technical data 68
– Transistor outputs 73
Index 75
