Flow Control
To change the setting, from the Main Menu select Setup, Port
Settings, then User Comm. Then, follow these steps:
1. Press L or R until you see
USER COMM
l Flow Control r
2. Press E. You will see the current setting, for example:
FLOW CONTROL
l DTR r
3. Press L or R to display the flow control you need, then
press E. Press e three times to exit to the Main Menu.
XON is 17; XOFF is 19. Set flow control to DTR for PC
computers (unless you have XON/XOFF software).
Reset to Default Values
To change the setting, from the Main Menu select Setup, Port
Settings, then User Comm. Then, follow these steps:
1. Press R until you see
USER COMM
l Reset
2. Press E. You will see
Are you sure?
No r
3. Press L or R to make your selection, then press E.
Press e three times to exit to the Main Menu.
5-4 Communication Values
