SECTION SIX – COMMANDS
DS2000 USER’S MANUAL (rev.C)
6.15
6.7.1 UTILITY MENU
6.7.1.1 UTILITY MENU - ANALOG OUT CONFIGURATION
The value set for Analog Out is the same in the J2 output.
ZERO SETTING ANALOG OUT
Description: it allows the setting to zero of the Analog Out preset value,
the output is kept to zero
SPEED REFERENCE
Description: Analog Out is configured as the speed reference; it can be
useful to verify how the reference signal sent by control is detected
SPEED ERROR
Description: Analog Out is configured as the speed error; it can be
useful to verify the proper execution of the set trajectories
|CURRENT REF. |
Description: Analog Out is configured as the current reference module.
The information can be useful to check the real load applied both by the
drive and the motor
ILIMIT
Description: Analog Out is configured as the current analog limit set.
U PHASE EL. POS.
Description: Analog Out is configured as the U phase electric position;
±10 V output corresponds to U phase angular position, between 0° and
360° electrical degrees.
V PHASE EL. POS.
Description: Analog Out is configured as the V phase electric position;
±10 V output corresponds to V phase angular position, between 0° and
360° electrical degrees.
U PHASE DET. CUR.
Description: Analog Out is configured as the instant value of the current
supplied by U phase. The analysis of the sinusoidal wave allows to point
out any eventual control problem
V PHASE DET. CUR.
Description: Analog Out is configured as the instant value of the current
supplied by V phase. The analysis of the sinusoidal wave allows to point
out any eventual control problem
U PHASE B.E.M.F.
Description: Analog Out is configured as the instant value of the
B.E.M.F. existing on the motor U phase; the analysis of the sinusoidal
wave correct shape allows to point out any eventual control problem
V PHASE B.E.M.F.
Description: Analog Out is configured as the instant value of the
B.E.M.F. existing on the motor V phase; the analysis of the sinusoidal
wave correct shape allows to point out any eventual control problem
U PHASE VOLTAGE
Description: Analog Out is configured as the instant value of the U
phase voltage (as a sum of B.E.M.F. and resistive drop). The analysis of
the sinusoidal wave correct shape allows to point out any eventual
control problem
V PHASE VOLTAGE
Description: Analog Out is configured as the instant value of the V
phase voltage (as a sum of B.E.M.F. and resistive drop). The analysis of
the sinusoidal wave correct shape allows to point out any eventual
control problem
