SECTION THREE – ELECTROMAGNETIC COMPATIBILITY (EMC)
DS2000 USER’S MANUAL (rev.C)
3.1
3. ELECTROMAGNETIC COMPATIBILITY (EMC)
3.1 INTRODUCTION
In this section are described the recommended drive installation procedure following EMC
standards. EMC filters are described in the 3.3 par. and the grounding and screening in the
3.4 par. and following. The installer of the drive is responsible for ensuring compliance with
the EMC regulations that apply where the drive is to be used.
3.2 EUROPEAN DIRECTIVE (89/336/EEC)
Compliance with the European Directive 89/336/EEC is required for all electric and electronic
products brought onto the European market after December 31st, 1995.
DS2000 drives meet the following EMC product standard related to the Directive:
EN 61800-3:1996 and EN 61800-3/A11:2000: "Adjustable speed electrical power drive
systems. Part 3: EMC product standard including specific test methods".
Second environment (industrial) compatibility levels.
Tests have been made in an independent test house.
3.3 FILTERS
3.3.1 FILTER TYPES
Trade-mark
Rated current [A]
at 50°C (40°C)
Max Voltage [V
ac
]
at 50°C
Drive type / input
Schaffner
FN2070-3-06
(3) 250 24V
dc
input
Schaffner
FN 258-7/07
7 (8.4) 3x480
DS2000 3/9
DS2000 4/12
DS2000 6/15
DS2000 8/22
Schaffner
FN 258-16/07
16 (19.2) 3x480 DS2000 14/42
Schaffner
FN 258-30/07
30 (36) 3x480
DS2000 20/45
DS2000 25/70
DS2000 30/90
Schaffner
FN 258-42/07
42 (50.4) 3x480 DS2000 50/140
Schaffner
FN 258-55/07
55 (66) 3x480 DS2000 60/180
Schaffner
FN 258-100/35
100 (113) 3x480 DS2000 100/300
Tab. 3.1 – Filter types
