SECTION ONE – DESCRIPTION
DS2000 USER’S MANUAL (rev.C)
1.6
1.5 STANDARD VERSIONS CODES
DS2000 drives are marked by a code identifying both the current supplied by the Model and
the eventual internal recovery resistor.
Codes correspond to:
• Standard Italian software drives
• 6 poles resolver (transformation ratio:0.29), ¼ marker configured, 1024 simulated
encoder pulses
• External recovery resistor, provided with the drive together with mating connectors.
The following table summarizes the drive codes:
Model
Code Type
Size
CZ1000C0A 3/9 A
CZ1001C0A 4/12 A
CZ1002C0A 6/15 A
CZ1003C0A 8/22 A
CZ1008C0A 14/42 B
CZ1005C0A 20/45 C
CZ1006C0A 25/70 C
CZ1007C0A 30/90 C
CZ1009C0A 50/140 D
CZ1010C0A 60/180 D
CZ1011C0A 100/300 E
Tab. 1.1 – Standard versions codes
Besides the coding in Tab. 1.1, a new coding formed by a descriptive code has been
introduced, which univocally and directly identifies a drive and its configuration.
Fig. 1.1 shows the new codifications .
