SECTION SIX – COMMANDS
DS2000 USER’S MANUAL (rev.C)
6.14
AFW THRESHOLD
Description: it indicates the actual value for the AFW intervention, for power lost
UV THRESHOLD
Description: it indicates the actual value for the undervoltage intervention
I2T IGBT ON
Description: it indicates how many times the IGBT protection started after last
power on
CHECKSUM FLASH
Description: it indicates the checksum calculated by the drive resident software
Attention: in case of mismatch between calculated value and mapped value the
program resident on memory may be damaged. It is necessary to reload the
program
6.7 UTILITY MENU
Fig. 6.7 – Utility menu
