SECTION TWO – WIRING AND INSTALLATION
DS2000 USER’S MANUAL (rev.C)
2.8
2.4 POWER DISSIPATION
For the thermal sizing of the cabinet in which the drive is installed, it is necessary to refer to
the table. If the application implies continuous braking, it is necessary to add the recovery
resistor power dissipation (use the nominal power if the one required by the application is
unknown).
DS2000 Model Power
3/9 60W
4/12 75W
6/15 90W
8/22 110W
14/42 180W
20/45 250W
25/70 300W
30/90 400W
50/140 650W
60/180 800W
100/300 1200W
Tab. 2.2 – Power dissipation at nominal current
2.5 SOFT-START
The soft-start circuit (current limit at start-up) is included in the drive input stage. Additional
data about the soft-start circuit can be found in the Section 5.
