Moog DS2000 User Manual

SECTION TWO – WIRING AND INSTALLATION
DS2000 USER’S MANUAL (rev.C)
2.39
2.16 MECHANICAL BRAKING
The FASTACT series motors have an optional electromagnetic brake with pressure springs
to be supplied with 24 V
dc
nominal voltage (24 to 26 V
dc
) at the motor terminal.
CAUTION: the brake must be used only for standing (with motor at standstill). The use of this
brake for dynamic braking seriously damages the brake and reduces the braking torque.
Note 1: t
1
≥ 300 ms, t
2
= application depending, t
3
= 100 ms, t
4
≥ 200 ms
Note 2: For FASTACT motors, size 3 and size 4, t
1
≥ 1000 ms
0 rpm
0V
CLAMP
OFF
OFF
t
4
t
3
t
2
t
1
24V BRAKE
POWER SUPPLY
DRIVE
ENABLE
BRAKE
MOTOR
SPEED
REFERENCE
ENABLE
RELEASE
ON
ON
Fig. 2.18 – Mechanical braking sequence times
