SECTION THREE – ELECTROMAGNETIC COMPATIBILITY (EMC)
DS2000 USER’S MANUAL (rev.C)
3.3
3.3.4 FILTER INSTALLATION
The filter must be mounted on the same drive panel.
CAUTION: leave a clear space at least 60mm around the filter for air circulation when the
cabinet does not have forced ventilation.
The filter must be connected as close as possible to the cabinet input. If the separation
between filter and drive exceeds around 30 cm (1 ft.) then a shielded cable should be used
for the RF connection between filter and drive.
NOTE: when mounting the drive and the filter to the panel, it is essential that any paint or
other covering material be removed before mounting the drive and the filter.
The maximum torque of mounting screws at terminal block is as follows:
FILTER Max torque
FN 258 - 7/07 0.8 Nm
FN 258 - 16/07 0.8 Nm
FN 258 - 30/07 1.8 Nm
FN 258 - 42/07 1.8 Nm
FN 258 - 55/07 3.0 Nm
FN 258 - 75/34 3.0 Nm
FN 258 - 100/35 4.0 Nm
Tab. 3.3 – Maximum torque of mounting screws at terminal block
WARNING: the filter can produce high leakage currents (see Filter Data Sheets)
WARNING: the filter must be connected to ground before connecting the supply
WARNING: High Voltage - Discharge time approx. 10 seconds
