CREASING / FOLDING
1st Fold 105.0
Home
More
Set Folds
2nd Fold 210.0
Back
Set Folds
Tens Decimals
(1st Fold 105.0)
2nd Fold 210.0
Back
Set Folds
Tens Decimals
(2nd Fold 210.0)
---
Adjust
Set Folds
Tens Decimals Tens Decimals
Tens Decimals Tens Decimals
Setting the Fold Positions.
11. Move the Selection Switch to the left (one click at a time) selecting until the
display shows the words as shown below.
12. Move the Selection Switch down to select the 1st Fold.
13. The 1st Fold position can then be adjusted by moving the Selection Switch to the
left to select or to the right to select . The or
(whichever has been selected) can then be adjusted by rotating the Selection Switch,
(clockwise to increase or anti-clockwise to decrease).
14. Move the Selection down to select the 2nd Fold position.
15. The 2nd Fold position can then be adjusted by moving the Selection Switch to the
left to select or to the right to select . The or
(whichever has been selected) can then be adjusted by rotating the Selection Switch,
(clockwise to increase or anti-clockwise to decrease).
1. The maximum number of folds per sheet = 2.
2. The Batch Quantity can be set, and the Program can be stored; as described on pages
18 and 19.
NOTES.
Operating the Digifold
