Operation
5-22 January 2019
Controller Options - Continued
Topcon - X35 Apollo - Continued
Hydraulic Pressure Control Setup - Continued
6. Testing Operation - With the tractor Hydraulics ON,
the openers should be in the UP position. When
Master Switch is engaged the openers will be lower
into the working position automatically.
Warning
Openers drop with full down force when
powering up or rebooting the X35 with
hydraulics engaged.
S65155
7. Special Operation - ON/OFF button when toggled
to OFF, allows the openers to Float over terrain in
the downward working position with no pressure
applied. This function is useful when travelling over
wash outs or in muddy conditions when the unit is
on the verge of becoming stuck.
