PARAMETER SPECIFICATIONS
118
processing are selected internally from the set II and V5 for detection, and V1 for
confirmation.
Beat Typing:
ECG Leads Used
3 lead:
Displayed ECG vector
5 lead:
 When configured to Auto, the ECG leads used for HR and ARR processing start with
II and V for detection and III for confirmation while allowing the algorithm to switch
to other available leads based on signal quality.
 When configured to Single Lead, the ECG lead used for HR and ARR processing is
the one specified by the user from the set I, II, III, or V.
 When configured to Multiple Leads, the ECG leads used for HR and ARR processing
are selected internally from the set II and V for detection, and III for confirmation.
AM12M:
 When configured to Auto, the ECG leads used for HR and ARR processing start
with II and V5 for detection and V1 for confirmation while allowing the algorithm
to switch to other available leads based on signal quality.
 When configured to Single Lead, the ECG lead used for HR and ARR processing
is the one specified by the user from the set I, II, III, or V (V1).
 When configured to Multiple Leads, the ECG leads used for HR and ARR
processing are selected internally from the set II and V5 for detection, and V1 for
confirmation.
VTach Rate Threshold
Configurable from 100-200 beats per minute. For a VTach condition to be considered, the
rate of the ventricular rate must be greater than the configured VTach rate.
VTach Count (PVC Run)
Configurable from 1-6 consecutive ventricular beats. For a VTach condition to be
considered, the length of the ventricular waveform must be greater than the configured
VTach length.
ST Analysis
ST Segment Analysis
Sensing leads: Any ECG lead available based on lead set used
ST Measurement Accuracy
Range: 2500 to +2500 µV, Mean Error = 7 µV (Std Dev = 63 µV) per EC57 on ESC-ST
database
Averaging
Over rolling 32 beats
Alarm Delay
60 seconds
