10. CONFORMANCE TESTING
Conformance Testing
Conformance testing is to be performed by Authorized Mortara Service Representatives to verify the device is
functioning correctly after repair operations have been performed. Testing results should be documented on
the test data record at the end of this section of the manual.
Required Equipment:
Qty
Part Number
Description
1
EL400 or equivalent
Vital Sign Simulator
1
N/A
NIBP Cuff
1
EL275
DMM
1
N/A
Power Driver 3.5 inch-pounds
1
N/A
Power Driver 5.0 inch-pounds
1
N/A
Nut Driver (7/32)
1
9293-052-50
CO2 Test Cable Filter Line Set
1
9293-050-60
5 Lead ECG Cable
1
9293-057-60
Finger Clip SpO2 Sensor (Mortara SpO2)
1
9293-057-51
Cable SpO2 Adaptor & Extension
1
6901-017-03
Finger Clip SpO2 Sensor Nellcor (SpO2)
1
6901-017-02
Cable SpO2 Adaptor & Extension Nellcor
1
TF-0567
AM12M Acquisition Module
2
TF-0560
IBP Test Cable
1
TF-0561
Temperature Test Cable
1
TF-0562
Cardiac Output Test Cable
1
TF-0563
USB Production Dongle
1
TF-0564
USB Test Harness Drive
1
TF-0565
Nurse Call Fixture
1
TF-0568
S12/S19 Power Test Fixture
2
N/A
Shorting Bar (applied parts)
Required to perform NIBP calibration (not required to perform preventive maintenance or conformance testing).
Qty
Part Number
Description
1
6901-011
Hose fitting
1
6901-022-01
Extension hose
1
N/A
Hand pump
1
TF0419
Alloy NIBP Rigid Vessel
1
N/A
Pressure measurement device
