Motion Control Engineering Motion 3000ES

Operating Adjustments
39
CT Drive Parameters (VVVF Drive Only)
Status
In status mode, the drive display shows the operating status of the drive:
• Auto tune: Auto tune in progress.
• inh: Inhibited; enable input is inactive.
• rdY: Ready; enable closed but inverter not active.
• StoP: Stopped; inverter active but holding zero speed/frequency.
• run: Running; inverter active and motor running.
• SCAN: Drive is trying to synchronize in regen mode.
• ACUU: Power mains lost; decelerating to zero in mains loss ride-through or stop modes.
• dEC: Decelerating; speed/frequency ramping to zero after a stop.
• dc: DC injection; DC injection stop active.
• POS: Position; position control active during orientation stop.
• triP: Tripped; drive has tripped.
• act: Active; regen unit is synchronized and inverter is active.
Displaying Drive Parameters
In parameter view mode, the first display row shows the menu parameter number and the sec-
ond the value of that parameter. To display drive parameters and check their current settings:
1. Use the mode button to select parameter view mode (upper line flashing in drive
display).
2. Use left and right arrows on rocker switch to select a menu.
3. Use up and down arrows on the rocker switch to select a parameter.
• Press up and down arrows simultaneously to return to the first parameter in a menu.
• Press left and right arrows simultaneously to return to Menu 0 (zero).
• The drive remembers the last parameter being viewed so when you leave, then return to
parameter view mode, that parameter will be displayed.
