Motion 3000ES Escalator Control
26 Manual # 42-02-E001
Initial System Startup
This section describes initial startup and adjustment.
•Prestart check
• Initial startup
Prestart Check
Before system startup:
• Check and correct any hazardous conditions
• Check/adjust installed components for:
•Smooth operation
• Proper adjustment to required tolerances
• Lubricate as required:
•Bearings
•Tracks
•Chains
•Guides
• Other hardware
•Ensure that:
• Step bands, skirts, and comb segments are in order
• No debris or equipment is in or on escalator
• All steps are fitted
• Safety devices and protective switches are properly installed
Construction Mode
Construction mode operation allows the escalator to be run on inspection only with a bare min-
imum of field wiring installed. For construction mode operation, only the following are needed
to run the escalator:
• Motor, brake, and drive (if used)
• Safety String (may be jumpered out initially if necessary)
1. To enter construction mode, set escalator parameter F5-07 to 1 (one). This setting
causes all faults to reset automatically while you are making initial adjustments.
• In construction mode, the escalator parameter display will show “-CH-” and the entry
displays will show “X”.
2. After completing adjustment, you must set F5-07 back to 0 (zero) before the escalator
will enter automatic operation.
• When F5-07 is set back to 0 (zero), the parameter display will show “STOP” and the
entry displays will show “SP”.
If safety devices are bypassed, take extreme caution to avoid personnel injury or equipment
damage. As safety equipment is installed, it must be wired into the safety string.
