CT Drive Reset/Parameters Table
If the drive has tripped or a reset is necessary for other reasons (refer to the drive manual), the
drive may be reset in one of two ways:
1. Stop button: If the drive has been set up such that the stop button is not operative, then
the key has a drive reset function only. Conversely, if the Stop button is operative, initi-
ate a reset by:
- Drive running: Hold the Run button and then press the Stop button.
- Drive stopped: Press the Stop button.
2. Reset the drive by setting Drive Reset parameter Pr 10.33 from 0 to 1. (A digital input
may be programmed to toggle this parameter.)
Please see the drive manual for additional reset information.
Table 13. CT Drive Parameters
Para Description Units Default MCE
0.00
Saving parameters
Enter pr. 0.00=1000 and press the red Reset button.
Restoring default Parameters
Enter pr. 0.00=1244 and press the red Reset button.
---- 0 0
0.01 Minimum Reference Clamp Hz 0 0
0.02 Maximum Reference Clamp Hz 60 60
0.03 Acceleration rate 1 s/100Hz 5 7
0.04 Deceleration rate 1 s/100Hz 10 4
0.05 Reference Selector ---- A1.A2 Pr
0.06 Symmetrical Current Limit % 165 165
0.07 Voltage mode select ---- Ur I Fd
0.08 Low Frequency Voltage Boost % 3.0 3.0
0.09 Dynamic V/F/Flux optimize Select ---- Off ON
0.10 Motor RPM (Read only) RPM 0 0
0.11 Output Frequency (Read only) Hz 0 0
0.12 Current Magnitude (Read only) Amps 0.00 0.00
0.13 T28 digital input 5 destination ---- 1.41 1.45
0.14 T29 digital input 6 destination ---- 6.31 1.46
0.15 T8 analog input 3 mode ---- th Volt
0.16 Preset Reference 1 Hz 0.00 1.3
0.17 Preset Reference 2 Hz 0.00 60.0
0.18
Preset Reference 3
Hz 0.00 30.0
0.19 Preset Reference 4 Hz 0.00 10.0
0.20 Relay source (Brake Release indicator) ---- 10.01 12.40
0.21 Ramp Mode Select ---- Fast Fast
0.22 S ramp enable ---- Off Off
0.23 Full power braking time Seconds 0.02 0.90
0.24 Full power braking period Seconds 2.0 2.0
0.25 Brake controller enable ---- diS USEr
0.26 Pre Brake release delay Seconds 1.0 1.0
0.27 Post brake release delay Seconds 1 0
0.28 Enable Forward/Reverse key ---- Off Off
0.29 Smart Card parameter data previously loaded ---- 0 1
