Motion 3000ES Escalator Control
42 Manual # 42-02-E001
* in the table above means that the value is set as required by customer job requirements.
0.30 Parameter Cloning ---- None None
0.31 Drive Voltage Rating Voltage 400/200
0.32 Maximum Heavy Duty Rating (Read Only) Amps 0
0.33 Catch a Spinning Motor ---- 0 0
0.34 User Security Code ---- 0 0
0.35 Serial Comms Mode ---- rtu rtu
0.36 Baud Rate ---- 19200 19200
0.37 Serial Address ---- 1 1
0.38 Current Loop Kp Gain ---- 20 20
0.39 Current Loop Ki Gain ---- 40 40
0.40 Auto Tuning ---- 0 0
0.41 Maximum Switching Frequency KHz 3 (8Khz) 3 (8Khz)
0.42 Number of motor poles Poles Auto
0.43 Rated Motor Power Factor ---- 0.85 0.85
0.44 Rated Motor Voltage Volts 460/230
0.45 Rated load rpm / rated speed RPM 1800
0.46 Motor Rated Current Amps 0
0.47 Motor Rated Frequency Hz 60
0.48 User Drive Mode of Operation ---- Open Loop Open Loop
0.49 Security Status ---- L1 L2
0.50 Drive Software Version 1.11 or >
Menu 2: Ramps
02.08 Standard Ramp Voltage Volts 775 775
Menu 8: Digital I/O
8.23 T26 Digital I/O 3 destination ---- 6.30 6.30
8.24 T29 Digital I/O 4 destination ---- 6.32 6.32
Menu 11: General Drive Setup
11.22 Parameter displayed at power-up ---- 0.10 0.10
Menu 12: Slot 3 Setup
17.13 Enable auto run ---- ON, 0FF OFF
Table 13. CT Drive Parameters
