Displaying Parameters in Real Time
When the escalator is running, you can cycle through parameters to check their settings by
pressing the UP or DOWN buttons on the display/keypad. The system must be running in Nor-
mal mode for the parameters to be viewed in real time.
• RUNT: Running time.
• USP1: Speed from S2 on EC-MCB.
• USP2: Speed from S3 on EC-MCB.
• USP3: Speed from S4 on EC-MCB.
• USP4: Speed from S5 on EC-MCB.
• DSP1: Speed from S6 on EC-SCB.
• DSP2: Speed from S7 on EC-SCB.
• DSP3: Speed from S8 on EC-SCB.
• DSP4: Speed from S9 on EC-SCB.
• RSTU: Operating status.
• CLOC: Current time.
• UPNP: Pulse phase differences on EC-MCB.
• DPNP: Pulse phase differences on EC-SCB.
•Cn-H: CAN high.
•Cn-L: CAN low.
