3
*
Top (Orange) Button
This button is usually programmed as the Emergency button.
4 Microphone
5 Accessory Connector
6 Home Button
Press to return to the Home screen.
7 4-Way Navigation Buttons
Use these buttons for list scrolling and navigating around the menu hierarchy.
8 Battery Latch
9 Keypad
Use the keypad to enter alphanumeric characters for dialing, contact entries, and text
messages.
10 Menu Select Buttons
Press to enter the menu corresponding to the button.
11 Main Display
12
*
3-Position A/B/C Switch
This switch is usually programmed for zone selection.
13 On/Off/Volume Control Knob
Rotate clockwise until you hear a click to turn on the radio.
Rotate counterclockwise until you hear a click to turn off the radio.
Rotate clockwise to increase the volume.
Rotate counterclockwise to decrease the volume.
14
*
2-Position Concentric Switch
This switch is usually programmed to enable or disable secure operation.
15 Top Display
16
*
Top Side (Select) Button
Use this programmable button to access a programmed function or enable or disable
a feature.
17 Push-to-Talk (PTT) Button
Press and hold to talk in simplex calls or to initiate a group call, release it to listen.
18
*
Side Button 1
Use this programmable button to access a programmed function or enable or disable
a feature.
19
*
Side Button 2
Use this programmable button to access a programmed function or enable or disable
a feature.
20 Battery
21 Bluetooth Pairing Location Indicator
22 Main Speaker
23 Microphone
*
These radio controls/buttons are programmable.
68012003048-GW
Chapter 3 : Radio Controls
21
