Getting Started
This section helps you to get familiar with the basic
operations of the radio.
7.1
Attaching the Battery
1 Slide the latch at the top of the battery door to the
unlock position, and lift the battery door at the center
recess.
a Align the battery contacts with the tabs in the
battery compartment. Insert the contact side of
the battery first, then press the battery down to
secure in place.
Figure 2: Attaching the Battery
1
3
2
2 Put the battery door back on the radio.
3 Slide the latch to the lock position.
7.2
Removing the Battery
1 Turn the radio off.
2 Slide the latch at the top of battery door to the
unlock position, and lift the battery door at the center
recess.
Figure 3: Removing a Li-Ion Battery
3 Pull the battery removal tab until the battery is
disengaged from the battery compartment.
4 Pull the battery away from the radio.
