Performance Checks: Display Radio Test Mode 5-5
Table 5-3. Test Frequencies (MHz) – VHF, UHF1, UHF2, 700/800 MHz
Test
Channel
VHF UHF1 UHF2 700/800 MHz
RX TX RX TX RX TX RX TX
F1
136.075 136.025 380.075 380.025 450.075 450.025 764.0625 764.0125
F2
142.075 142.125 390.075 390.025 460.075 460.025 769.0625 769.0125
F3
154.275 154.225 400.075 400.025 471.075 471.025 775.9375 775.9875
F4
160.175 160.125 411.075 411.025 484.925 484.975 851.0625 794.0125
F5
168.125 168.075 424.975 424.925 485.075 485.025 860.0625 809.0125
F6
173.925 173.975 435.075 435.025 495.075 495.025 869.9375 823.9875
F7
– – 445.075 445.000 506.075 506.025 851.0625 851.0125
F8
– – 445.075005 445.000005 519.925 519.975 860.0625 860.0125
F9
– – 457.075 457.025 – – 869.9375 869.8875
F10
– – 469.975 469.925 – – – –
Table 5-4. Test Environments
Display Description Function
CSQ Carrier
Squelch
RX: unsquelch if carrier detected
TX: mic audio
TPL Tone
Private-Line
RX: unsquelch if carrier and tone (192.8 Hz)
detected
TX: mic audio + tone (192.8 Hz)
AST ASTRO RX: none
TX: Digital Voice
***
USQ Carrier
Unsquelch
RX: unsquelch always
TX: mic audio
***All deviation values are based on deviation tuning of this
mode.
