Motorola APX 1000 - Specifications for APX 2000;APX 4000;APX 4000 Li UHF2 Radios

xxii Specifications for APX 2000/APX 4000/APX 4000Li UHF2 Radios
Specifications for APX 2000/APX 4000/APX 4000Li UHF2 Radios
All specifications are per Telecommunications Industries Association TIA-603 unless otherwise
noted.
GENERAL RECEIVER TRANSMITTER
Temperature Range:
Operating: -30°C to +60°C
Storage: -40°C to +85°C
Power Supply:
Lithium-Ion Battery (Li-Ion)
Battery Voltage:
Nominal: 7.5 Vdc
Range: 6 to 9 Vdc
Transmit Current Drain (Typical): 1960 mA
Receive Current Drain (Rated Audio): 293 mA
Standby Current Drain: 133 mA
Recommended Battery:
Li-Ion (Slim): NNTN8128_
or Li-Ion High Cap: NNTN8129_*
or Li-Ion High Cap: PMNN4424_
* FM Intrinsically Safe.
Dimensions (H x W x D):
Without Battery (Radio Only):
H = 5.26" (133 mm)
W
1
= 2.56" (65 mm) / 2.37" (60.2 mm)
D
2
= 0.77" (19.6 mm) / 1.48" (37.5 mm)
With Standard Battery:
H = 5.26" (133 mm)
W
1
= 2.56" (65 mm) / 2.37" (60.2 mm)
D
2
= 1.47"(37.4mm) / 1.72"(43.6mm)
With High Cap Battery:
H = 5.26" (133mm)
W
1
= 2.56"(65mm) / 2.37"(60.2mm)
D
2
= 1.69"(42.9mm) / 1.93"(48.9mm)
Note:
H = Height; W = Width; D = Depth
1 = (Width @ Top) / (Width @ PTT)
2 = (Depth @ Bottom) / (Depth @ PTT)
Weight: (w/o Antenna):
Less Battery: 9.17 oz (260g)
With Li-Ion Standard: 14.47 oz (410g)
With Li-Ion High Cap: 14.81 oz (420g)
Frequency Range: 450–520 MHz
Bandwidth: 70 MHz
Analog Sensitivity (typical)
(12 dB SINAD): 0.234 µV
Digital Sensitivity (typical)
(1% BER): 0.307 µV
(5% BER): 0.207 µV
Intermodulation (typical): -77 dB
Selectivity
(typical):
(25 kHz Channel): -77 dB
(12.5 kHz Channel): -67 dB
Spurious Rejection (typical): -80 dB
Frequency Stability
(-30+60°C; 25°C reference): ±0.0001%
Rated Audio:
Internal Speaker: 500 mW
External Speaker: 500 mW
FM Hum and Noise (typical):
25 kHz -53.5 dB
12.5 kHz -47.4 dB
Distortion (typical): 1 %
Channel Spacing: 12.5/25 kHz
Frequency Range: 450–520 MHz
RF Power:
450–520 MHz: 1–5 W
Frequency Stability (typical)
(-30 to +60°C; 25°C ref.): ±0.0001%
Emission (typical conducted): -75 dBc
FM Hum and Noise (typical)
(Companion Receiver): 25 kHz -51 dB
12.5 kHz -45 dB
Distortion (typical): 1%
Modulation Limiting: 25 kHz chnls ±5.0 kHz
20 kHz chnls ±4 kHz
12.5 kHz chnls ±2.5 kHz
ACPR (typical): 25 kHz -73 dBc
12.5 kHz -68 dBc
Emissions Designators:
11K0F3E, 16K0F3E, 8K10F1D, 8K10F1E,
8K10F1W, 20K0F1E
Specifications subject to change without notice.
