Motorola APX 1000 - APX 2000; APX 4000 (Two Knobs) Back Kit Exploded View Parts List

Exploded Views and Parts Lists: APX 2000/ APX 4000 (Two Knobs) Back Kit Exploded View Parts List 10-5
10.4 APX 2000/ APX 4000 (Two Knobs) Back Kit
Exploded View Parts List
NOTE:
†
. Items cannot be ordered individually. They are included in their respective kits (if ordered). Refer to the Model
Charts on pages xi, xiii, xv or xvii.
††
. Item is not orderable.
Item
No.
Motorola Part
Number
Description
42 0386104Z04 Screw, Chassis
43 0104063J03 Assembly, Flex, Back-kit
44 0104046J48 Shield, Secondary Assembly
45
†
PMLF4141_
PMLD4694_
PMLE5025_
PMLE5026_
Assy, PCB, Main 7/800 MHz
Assy, PCB, Main VHF
Assy, PCB, Main U1
Assy, PCB, U2
46 6071520M01 Cell, Coin
47 7515719H02 Pad, Thermal, RF PA
48 32012156001 O-ring, Main
49 43012045001 Collar, Plastic
50 64012022001 Back Mic Backer
51 0104059J61 Assembly, Flex, Back Mic
52 32012282001 Boot, Back Mic
53 35012068001 Membrane, Back Mic
54 CH000067A01 Chassis
55 32012150001 Seal, Battery Contact
56 3286058L01 Seal, Vacuum Port
57 5478220A01 Label, Ventilation
58
††
54012242001 Label, FCC
59
††
33012034001 Label, ITID
60 HN000165A01
HN000165A02
Shroud, Yellow
Shroud, Black
61 NNTN8129_
NNTN8128_
PMNN4424_
PMNN4448_
NNTN8560_
Battery, Hi-Cap (FM, 2300 mAH)
Battery, Standard (non-FM, 1900 mAH)
Battery, Hi-Cap (non-FM, 2300 mAH)
Battery, Hi-Cap (Non-IS, 2700 mAH)
IMPRES Li-Ion High Cap Battery (TIA4950)
62 PMLN4651_
PMLN7008_
Clip, Belt (2”)
Clip, Belt (2.5”)
