8-4 Disassembly/Reassembly Procedures: Fastener Torque Chart
8.3 Fastener Torque Chart
Table 8-3 lists the various fasteners by part number and description, followed by the torque values
and the location where used. Torque all fasteners to the recommended value when assembling the
radio.
Table 8-3. Fastener Torque Chart
Motorola
Part Number
Description Repair Torque (in-lbs)
0386104Z04 Speaker retainer (1) 4.6
0386104Z04 Chassis screw
(42) 3
0378212A02 Keypad retainer screw
(33) 1.2
FN000080A01 Nut, Volume Switch Spanner
(25) 8
0275000H02 Nut, Switch Spanner
(6) 8
FN000083A01 Top Bezel screw
(23) 8
