Exploded Views and Parts Lists: APX 1000 Front Kit Exploded View Parts List 9-3
9.2 APX 1000 Front Kit Exploded View Parts List
NOTE:
†
. Items cannot be ordered individually. They are included in the Assembly, Front-Kit – PMLN6805_ (Model 2),
PMLN6645 _ (Model 3) and PMLN6654_(Model 1.5). Refer to the Model Charts on pages xi, xii, xiii and xiv.
††
. Items can be ordered individually, but they are included in their respective kits (if ordered).
†††
. Item can be ordered individually, but Keypad with Part No. 75012114001, 75012114003 and 75012207001
are also included in PMLN6645_, PMLN6805_ and PMLN6654_ respectively.
Item
No.
Motorola Part
Number
Description
1 15012142001 Cover, Accessory-Connector
2
†
0104059J79
0104061J96
0104059J78
Assembly, Front Housing Kit (Model 1.5)
Assembly, Front Housing Kit (Model 2)
Assembly, Front Housing Kit (Model 3)
3 54012241001 Label, Bottom
4
††
54012198004 Label, Back (APX 1000)
5
††
54012196002 Label, Front_Product
6
††
36012020002 Knob, Multi Function
7 PMAE4065_
NAF5085_
NAR6593_
NAR6595_
FAF5259_
FAF5260_
PMAF4008_
Antenna UHF/GPS
Antenna Whip 700/800/GPS
Antenna VHF/GPS
Antenna 1/4 Wave 700/800 MHz Stubby/GPS
Antenna,UHF_R1 Plus GPS Stubby Antenna
Antenna,UHF_R2 Plus GPS Stubby Antenna
Antenna, 900/GPS
8
†††
75012114001
75012114002
75012114003
75012114004
75012114005
75012114006
75012207001
Keypad, Model 3 (English)
Keypad, Model 3 (Chinese)
Keypad, Model 2
Keypad, Model 3 (Cyrillic)
Keypad, Model 3 (Arabic)
Keypad, Model 3 (Hebrew)
Keypad, Model 1.5
9
††
40012056001
40012056002
40012085001
Mylar with Metal Domes, Keypad (Model 3)
Mylar with Metal Domes, Keypad (Model 2)
Mylar with Metal Domes, Keypad (Model 1.5)
10
††
PMCN4037_
PMCN4040_
PMCN4036_
Assembly, Keypad Board (Model 3)
Assembly, Keypad Board (Model 2)
Assembly, Keypad Board (Model 1.5)
11
††
0104059J56 Assembly, Keypad Flex (APX 1000)
12
††
42012056001 Retainer, Keypad
13
††
0378212A02 Screw, Retainer, Keypad
14
††
75012224001 Conductive Pad, Keypad Retainer
