5
English
RADIO OVERVIEW
ACCESSORY INFORMATION
Attach the Battery
Remove the Battery
1 Align the battery to the battery rails on the
back of the radio (approximately 1/2 inch from
the top of the radio.)
2 Press the battery firmly to the radio and slide
the battery upward until the latch snaps into
place.
3 Slide the battery latch, located on radio
bottom, into the lock position.
1 Turn OFF the radio if it is turned ON (see
page 20).
2 Slide the battery latch into the unlock position.
Disengage by pushing downward and holding
the latch towards the front of the radio.
3 With the battery latch disengaged, slide the
battery down from the top of the radio about
1/2 inch. Once the battery is free from the
battery rails, lift it directly away from the radio.
Battery Latch
Locked
Unlocked
