36 Desktop Mounting
Desktop Tray HLN6404
Figure 38 Desktop Tray HLN6404
Table 5 Mechanical Parts for Desktop Tray HLN6404
Post. Part No Description
1 3580009K01 Grille Cloth, Speaker
2 5080085D03 Speaker, 75 x 44 mm dual (not
applicable for HLN6405)
3 7510606A06 Bumper Rubber Black
4 0384725C09 Screw Tap 4.2 x 16
5 1580155J01 Housing, Desktop Tray
6 3002509Y01 Cable, Desktop Tray
7 4205722C02 Clip Fastener
8 4282018H18 Cable Retainer
9 1580154J02 Cover, Desktop Tray
10 7505190X01 Spacer, Desktop Tray
