Repair Section
73
9.4 Removal of Electrical Components
ILL00248-00
Stop Switch
Box
Inductor Coil
Stay
Terminal Block 1
AC Fan Motor
Noise Filter
Ground Bolt
Relay Board and
Bracket Assembly
Terminal Block 2
Ground Bolt
