CA Series User’s Manual Hardware Installation
2-3
CA-114
SW3
SW4 Serial Interface
SW5
SW1: I/O Base Address
SW2: Interrupt Vector
PC/104 Slot
Box Header Connector
CA-134I, CA-132 V2, CA-132I V2
RS-422/RS-485
2-WIRE/4-WIRE
SW1: I/O Base Address
SW2: Interrupt Vector
PC/104 Slot
Box Header Connector
20-pin for CA-132 V2, CA-132I V2
40-pin for CA-134I
CA-104 V2
SW2: Interrupt Vector
SW1: I/O Base Address
Box Header Connector
PC/104 Slot
